HARDWARE FEATURES | |
---|---|
Standards and Protocols | IEEE 802.3i 802.3u 802.3ab 802.3x |
Interface | 8 10/100/1000Mbps RJ45 Ports AUTO Negotiation/AUTO MDI/MDIX |
Fan Quantity | Fanless |
Physical Security Lock | No |
External Power Supply | External Power Adapter (Output: 9VDC / 0.6A) |
Jumbo Frame | 15 KB |
Switching Capacity | 16 Gbps |
Dimensions ( W x D x H ) | 7.1 × 3.5 × 1.0 in. (180 × 90 × 26 mm) |
Max Power Consumption | 4.6W |
Max Heat Dissipation | 15.8 BTU/h |
SOFTWARE FEATURES | |
---|---|
Transfer Method | Store and Forward |
MAC Address Table | 4K |
Advanced Functions | Green Technology, saving power up to 80% 802.3x Flow Control, Back Pressure |
OTHERS | |
---|---|
Certification | FCC, RoHs |
Package Contents | 8-Port Gigabit Desktop Switch TL-SG1008D Power Adapter Installation Guide |
Environment | Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~60℃ (-40℉~140℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
